Tyre Logo Laser Marking Equipment

Cov cuab yeej no yog tsim rau laser npav logos ntawm lub log tsheb sidewalls thiab yog siv nyob rau hauv kev tsim thiab tsim ntawm semi-steel ntsiag to log tsheb thiab self-sealing roj hmab log tsheb. Siv laser txiav cim tshwj xeeb logos, qauv, thiab lwm yam nyob rau sab ntawm cov log tsheb tiav. Thaum lub sij hawm cov txheej txheem, cov plua plav yuav rov zoo li qub, cov ntxhiab tsw raug tshem tawm, thiab tsis muaj kuab paug rau ib puag ncig. Tom qab kos npe tiav lawm, lub cim zoo yuav raug kuaj pom.

Lub log tsheb tu cov khoom siv ntau lawm: log tsheb conveyor txoj siv, lub log tsheb nruab nrab ntawm lub log tsheb, lub log tsheb laser npav qhov system, txias dua, flipping device, plua plav sau qhov system, nruas tso zis kab thiab kev ruaj ntseg guardrail.

Tyre Specification

Tsis muaj.	Qhov project	Hnub tim
1)	Tyre sab nraud txoj kab uas hla (ᴓA)	400-930 hli
2)	Tire hlaws hlaws (ᴓB)	14''-24''
3)	Tire seem dav (a)	105-415 hli
4)	Tire dav (b)	90-345 hli
5)	Tire qhov hnyav tshaj plaws	40kg ua

daim duab flow

Layout

Tsis muaj.	Qhov project	Tsis muaj
1	Khoom siv ntev:	7.5m
2	Khoom siv ntev:	Tsawg dua los yog sib npaug li 3m
3	Khoom siv ntev:	Tsawg dua los yog sib npaug li 3m

Tsis muaj

Tsis muaj.	Qhov project	Ntaus lub npe	Parameter ntsuas
1	Log tsheb conveyor siv	Universal pob conveyor mesh siv	PY{{0}} hom suab 50.8, thickness 16mm, conveying ceev 40m/min K series helical iav reducer 0.75/1.5
		Tire pre-centering ib qho kev tso tawm mechanism	Cov menyuam conveyor kab, txoj kab uas hla 60mm, ntev 1050mm, saw tsav 10A / 12A, conveying ceev 40m / min
		barcode scanning mechanism	Centering raug ± 3 hli (nrog SMC hluav taws xob proportional valve)
2	Tyre laser marking system	Laser etching tshuab	Laser zog 100W, laser Ruike / Chuangxin series. Lub sij hawm ua hauj lwm ntawm lub taub hau laser thiab txhawb lub reflector yog ntau tshaj 50, 000 teev
		Kaw etching chav	Cov chav tiv thaiv tau txais ib qho kev kaw tag nrho humanized tsim, uas zoo nkauj thiab yooj yim rau nqus. Khoom siv ntev 2460mm * dav 1800mm * qhov siab 2768mm
		Lifting clamping rotating mechanism	Nws txais FESTO tus qauv 80 * 300 ob lub tog raj kheej thiab plaub-qhia pas nrig qauv kom ruaj khov nqa.
3	cua txias system	Tshwj xeeb domain chiller	Txias Qhov siab tshaj plaws ntws yog 10L / min, cov dej kub yog 21 degree ± 3 degree, thiab lub tank ntim dej yog 6L.
4	tig ntaus ntawv		Nruab nrog SEW helical iav reducer raws li lub log tig tsav. Ib qho kawg ntawm cov hlua hluav taws xob sab sauv thiab sab qis yog tsau, thiab lwm qhov kawg tuaj yeem txav mus los.
5	hmoov av sau system	Pulse plua plav collector DB3000-4	The maximum air volume is 3000m³/h, the processing quality is >99% kev huv, cua siab yog siab dua los yog sib npaug rau 2.6kpa, thiab lub thoob ntim plua plav yog ntau dua lossis sib npaug li 11L.
6	laj kab kev nyab xeeb	1550*800	Khoom xim: dub (PAL9005) daj (PAL1023).
7	Roller tso zis kab	QY-1250/800	Qhov siab yog 800mm ± 50mm adjustable, qhov dav yog 1072mm, txoj kab uas hla yog 60mm, ntev yog 1050mm, cov saw tsav yog 10A / 12A, thiab conveying ceev yog 40m / min.
